Rubber Cone Fenders

Item Code: RC0807
Request a quotation

Key Features

  • Highly efficient even in severe angular berthing
  • PIANC standard approved
  • Incredibly stable cone fender shape resists shear
  • Strong and maintains performance
  • Versatile design suits numerous applications
  • Wide choice of rubber compounds
  • Proven design with thousands installed worldwide

Product Description

Our rubber cone fenders are manufactured from a high-quality rubber compound, and have been specifically designed for use in marine berthing applications. They combine excellent energy absorption with low reaction force upon contact in order to berth vessels of all sizes. Our cone fenders are the technological evolution of “cell” fenders, providing the most efficient performance of any fender type.

The conical design of our rubber cone fenders has been developed to provide stability at all times, regardless of the shear, axial or angular force. The large circular base also allows for secure installation to a wide variety of surfaces. It ensures that any energy is deflected away from the marina or dock. Cone fender systems can be used to berth a range of ship types such as; RoRo, Tankers and Cruise Ships. It is also suitable for use on structures such as; container and bulk terminals, general cargo facilities.

Rubber cone fenders use a design that is strong, well provide and used by facilities worldwide. For superior abrasion and wear resistance, The Rubber Company can provide steel frontal frames with a UHMW-PE face. This not only aids in the berthing process, but also serves to increase the life expectancy of the cone fenders. The UHMW-PE face can be swapped out, ensuring that the fender system provides optimal energy absorption at all times.

Specifications

Application: Berthing applications for; Marinas, Container terminals, Oil facilities, RoRo & Cruise terminals
Product: Rubber Cone Fenders
Hardness (Shore A): Varies depending on material & design
Material: Natural Rubber / SBR as standard
Colour: Black

Potential Applications

  • Container terminals
  • Cargo berths
  • Oil facilities
  • RoRo & cruise terminals
  • Dolphins & monopiles

Technical Data

Properties Test Method Values
Compound - NR / SBR
Density (Specific Gravity) DIN 53505 1200 kg/m3
Tensile Strength DIN 53504 ≥16 MPa
Elongation at Break DIN 53504 ≥350%
Tear Resistance (23°C) DIN 53507 ≥80 N/cm
Abrasion Resistance DIN 53516 ≤100mm3
Compression Set (24hrs @ 70°C) DIN 53517 ≤40%
Ozone Resistance (ppm 20% 72hrs @ 40°C) ISO 143/1 No cracking visible by eye
Minimum Temperature - -30°C
Maximum Temperature - +70°C
