Products

British Manufacturer

Flame Retardant Silicone Sheets

Item Code: RC0323-FR
Request a quotation

Key Features

  • High quality product
  • Excellent flame retardant properties
  • Good physical properties
  • Good thermal & sound insulation properties
  • Good resistance to weathering, UV & Ozone
  • Lightweight
  • Easy to cut and shape to size

Material Accreditations

  • BS 6583 Cat 1A
  • NF F 16-101 12, F0
  • CEN TS 45545-2-HL2 for R1, R7, R22 & R23 materials
  • UL94V0 @ 3mm
  • LUL 1-085

Product Description

Our flame retardant silicone sheets are the perfect product for use in fire or direct heat contact applications. This product offers unbeatable self-extinguishing properties. We can supply this product in a sheet size of 1m x 1m. You also have a choice of thicknesses ranging from 1mm – 8mm. This ensures that you always get the perfect product to suit the application.

At a 3mm thickness our flame retardant silicone sheeting meets UL94V0 flammability standards. It also conforms to BS6853, Cal 1A as well as TS EN 45 545-2 safety standards. This ensures that our product has been independently tested and deemed fire safe in a wide variety of applications and environments.

Aside from offering excellent flame retardant properties, this product also offers many of the useful properties that standard silicone provides. It features a wide functioning temperature range, resistance to many common chemicals as well as weathering and UV damage. This product is also non-toxic and fungus resistant.

Specifications

Application: High temperature & flame retardant applications
Product: Flame retardant sheeting
Hardness (Shore A): 68°
Material: Silicone
Colour: Grey

Potential Applications

  • Automotive industries
  • Gaskets & O-rings
  • High temperature seals
  • Vibration insulators
  • Construction industries
  • Heating & Ventilation (HVAC)

Technical Data

Properties Values
Tensile Strength 10.2 MPa
Elongation at Break 320%
Compression Set (24h, 175°C) 20%
Compression Set (22h, 350°F) 20%
Operating Temperature -45°C to +200°C
Brittle Point -80°C (-112°F)
Limiting Oxygen Index 37.0%
Thermal Conductivity 0.24 W.m-1 .K.1
Radiation Resistance >105 Grays (107 Rads) typical
Dielectric Strength 23 kV.mm-1
Dielectric Constant 2.9
Dissipation Factor 3x10-3
Volume Resistivity 8x1015Ω.cm
